Product model
Outline Dimension
Visual Area
YHBC240128A 144.0mm x 104.0mm 114.0mm x 64mm
YHBC240128B 144.0mm x 104.0mm 114.0mm x 64mm
YHBC240128C 144.0mm x 104.0mm 114.0mm x 64mm
YHBC240128D 144.0mm x 104.0mm 114.0mm x 64mm
YHBC240128E 170.0mm x 95.0mm 124.0mm x 70mm
YHBC240128F 159.4mm x 101.0mm 124.0mm x 70mm
YHBC240128G 144.0mm x 104.0mm 114.0mm x 64mm
Display Type: 240128 Graphic
IC Options: T6963C/RA6963 /SAP1024B
Interface: Parallel Port
Product pin : 20 pin
Driving Voltage: 5V or 3.3V
LCD Colors: Yellow-Green/Blue/Grey/FSTN/other
